Visual field testing without boundaries

Full field static perimetry

A test for various indications

The Octopus 900 offers a wide range of static perimetry tests. It includes pattern for the central visual field testing like G, M, 24-2, and 10-2 as well as patterns for the periphery with the 07 test. Low vision tests, the binocular Esterman test for driving assessments, and custom tests complete the offering. Most tests take 2-4 minutes with the TOP strategy.

Read more

Octopus & HFA printouts

Flexibility for your practice

Thanks to its flexible printouts, results can be viewed in Octopus and HFA-style. There are standard printouts like the 7-in-1 and the HFA Single Field Analysis. Series and trend views support identification of change and the both eyes display is useful to identify neurological defects. Various customization options complete the offering.
Read more

EyeSuite glaucoma analysis

Viewing glaucoma from different angles

The Octopus 900 allows you to view glaucoma visual field series form different angles. Have a look at the highly sensitive Cluster Analysis, the Polar Analysis for structural comparison for single field and progression.

Read more

Kinetic perimetry

The modern Goldmann Perimeter

Appreciate the same parameters and flexibility as offered by the original manual Goldmann perimeter while benefitting from simplified and more consistent operation and even age-corrected normal values.

Read more


The key for reliable results

The user-oriented workflow of the Octopus 900 perimeter can reduces operator errors and supports reliable perimetric results. A guided step-by-step examination process, patient instructions in multiple languages and automated fixation control, that addresses with fixation loss automatically, further simplify the use of the device.

Read more


Integration into practice workflows

The EyeSuite software has been designed to support patient flow in busy practices. It controls many Haag-Streit devices and allows for them to be networked with other Haag-Streit devices, an office computer, or an EMR system without the need for any third-party software.

Read more
Octopus 900 Basic Octopus 900 Pro
Stimulus projection
Stimulus size (Goldmann) I - V I - V
Max stimulus intensity 10000 asb 10000 asb
Test methods
Blue-on-yellow (SWAP)
Red Stimuli
Kinetic (manual and semi-automated)
Test strategies
TOP Strategy (full threshold, 2-4 min)
Custom test options
Free choice of stimulus size
Free choice of stimulus locations
Stimulus duration (ms) 100, 200, 500, 1000, infinite
Stimulus color (Blue, red, white)
Background color (White, yellow)
Background illumination (asb) 0, 4, 31, 314
Analysis software
Single field view (7-in-1, single eye, both eyes, user-defined, HFA-style)
Series view
Global progression (MD, sLV, DD, LD)
Cluster Trend
Polar/Optic Nerve Head (ONH) Trend
Special features
Motorized trial lens holder
Fovea threshold
Trial lens holder distance monitoring
Pupil measurement
Fixation Control
Customized spherical trial lenses (-11, -12 dpt)
Pedriatric chinrest
External PC (Windows only)
Integrated PC (Linux embedded)
Integrated touch screen
EMR, Ethernet
Connect to network printer
Connect to shared folder
Connect to remote database
Data import
Octopus 101, 900, 123, 300 and 600
Data export
Raw data for research
Weight (kg / lbs) 12.7 kg / 28 lbs 12.7 kg / 28 lbs
● standard | ○ optional | − not available | □ not recommended
