Microscopes opératoires pour l'ophtalmologie
Microscopes chirurgicaux
Les microscopes chirurgicaux ophtalmiques de Haag-Streit se distinguent par une optique exceptionnelle et une ergonomie innovante. Dotés d'optiques de haute précision fabriquées en Suisse, les microscopes de Haag-Streit sont connus pour leur visualisation haute résolution et leur profondeur de champ améliorée. Une ergonomie bien pensée aide les chirurgiens ophtalmologistes à travailler au mieux.
Comparer nos produits
| Hi-R NEO 900 Microscope | |
|---|---|
| Accessoires (sélection) | |
| Microscrope rotation (°) | 540 |
| Controls | |
| Integrated status display | ● |
| Graphical user interface for user specific presets and controls | ● |
| Foot switch with up to 14 functions | ● |
| Electromagnetic brakes for microscope and floor stand | ● |
| Hand switch button programmable | − |
| Dimensions | |
| Floor stand carriage (mm / inch) | 732 x 727 mm / 28.82 x 28.62 inches |
| Arm reach, max. (mm / inch) | 1320 mm / 51.97 inches |
| Height at oculars (mm / inch) | 1063 to 1783 mm / 41.85 to 70.2 inches |
| Min. door height (mm / inch) | 1939 mm / 76.34 inches |
| Microscope weight, without accessories (kg / lbs) | 9.2 kg / 20.28 lbs |
| Floor stand weight (kg / lbs) | 230 kg / 507 lbs |
| Focal length | |
| Focal length 200mm / 7.87 in | ● |
| Focal length 175mm / 6.89 in | ○ |
| Illumination | |
| LED illumination | ● |
| Protection filter: UV, IR | ● |
| Slit illumination | ● |
| Filters: UV, soft light, daylight, blue | ● |
| Slit and spot illumination | ● |
| Retina protection filter [nm] | ● |
| Filters: blue light, soft light | ● |
| Movement ranges | |
| Floor stand arms swivel (deg.) | 2x 270 |
| X-Y coupling movement (mm / inch) | 60 x 60 mm / 2.36 x 2.36 inches |
| Microscope inclination (deg.) | -70 to +90 |
| Visualization | |
| Red reflex enhancer | ● |
| Stereo base: 25mm / 0.98 in | ● |
| Optics with apochromatic properties | ● |
| Motorized zoom with 1:6 ratio | ● |
| Motorized focus, range: 50mm / 1.97 in | ● |
| Integrated depth of field | − |
| Microscope | |
| Inclined eyepiece | ● |
● standard | ○ optional | − not available | □ not recommended
