Leistung und Langlebigkeit seit 90 Jahren
Spaltlampe
Haag-Streit Spaltlampen haben sich einen legendären Ruf für ihre Leistung und Langlebigkeit erworben. Seit mehr als 90 Jahren achten wir auf jedes Detail und setzen uns dafür ein, die besten Spaltlampen herzustellen, damit Ihnen kein Detail entgeht.
Vergleiche unsere Produkte
BQ 900 | BP 900 | BI 900 | BM 900 | BX 900 | |
---|---|---|---|---|---|
Microscope | |||||
Galilean microscope | ● | ● | − | − | ● |
Kepler microscope | − | − | ● | ● | − |
Stereo angle 13° | ● | ● | ● | ● | ● |
Stereo variator (stereo angle 4.5°) | ○ | − | − | − | □ |
Inclined eyepiece | ○ | − | − | − | ○ |
Yellow filter | ○ | ○ | ● | − | ○ |
Second observer tube | ○ | − | − | − | □ |
Beam splitter | ○ | − | − | − | □ |
Magnification (Std. Eyepieces) | |||||
6.3 × | ● | − | − | − | ● |
10 × | ● | ● | ● | ● | ● |
16 × | ● | ● | ● | ● | ● |
25 × | ● | ● | − | − | ● |
40 × | ● | − | − | − | ● |
Illumination | |||||
LED | ● | ● | ● | ● | ● |
Background | ○ | ○ | ○ | − | ● |
Tilt | ● | ● | ● | ● | ● |
Defocusing | ● | ● | ● | ● | ● |
Short illumination mirror | ○ | ○ | ○ | ○ | ○ |
Filter | |||||
Gray | ● | ● | ● | ● | ● |
Red-free | ● | ● | ● | ● | ● |
Blue | ● | ● | ● | ● | ● |
Slit | |||||
Width (continuous) (mm / inch) | 0 - 14 mm / 0 - 0.55 inches | 0 - 14 mm / 0 - 0.55 inches | 0 - 14 mm / 0 - 0.55 inches | 0 - 8 mm / 0 - 0.315 inches | 0 - 8 mm / 0 - 0.315 inches |
Length (continuous) (mm / inch) | 1 - 14 mm / 0.394 - 0.55 inches | 1 - 14 mm / 0.394 - 0.55 inches | 1 - 14 mm / 0.394 - 0.55 inches | 1 - 8 mm / 0.039 - 0.315 inches | 1 - 8 mm / 0.039 - 0.315 inches |
Test mark fixation star | ● | ● | ● | ● | ● |
Imaging | |||||
IM 910 | ○ | − | − | − | − |
IM 600 | ○ | ○ | − | − | − |
Imaging Set BI 900 | − | − | ○ | − | − |
DSLR camera connector | − | − | − | − | ● |
Integrated flash (slit and background) | − | − | − | − | ● |
Tonometry | |||||
AT 900 mod. BQ | ○ | ○ | − | − | □ |
AT 900 mod. R | − | − | ○ | ○ | − |
AT 900 mod. T | ○ | ○ | ○ | ○ | − |
Dimensions | |||||
Weight (kg / lbs) | 12.7 kg / 20.28 lbs | 12.3 kg / 27.11 lbs | 12 kg / 26.45 lbs | 11.4 kg / 25.13 lbs | 14.8 kg / 32.63 lbs |
Dimensions L x W x H (mm / inch) | 305 x 332 x 700 mm / 12 x 13 x 27.56 inches | 305 x 332 x 700 mm/ 12 x 13 x 27.56 inches | 310 x 332 x 700 mm / 12.2 x 13 x 27.56 inches | 290 x 332 xx 700 mm / 11.42 x 13 x 27.56 inches | 370 x 332 x 800 mm / 14.57 x 13 x 31.5 inches |
● standard | ○ optional | − not available | □ not recomended
